Zoom Lenses

Large Format - Super35 - Super16

Fujinon Premist Large Format zoom 28-100 zoom lens
Angenieux EZ zoom
Canon CN-E 30-105 zoom lens
ARRI Signature 45-135 zoom lens

Home ➞ All Equipment ➞ Lenses ➞ Zoom Lenses

Fujinon Premista Zoom

Fujinon Premista Large Format

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
28-100 2' 6" 2.9 -22 8: 6oz 114mm 46.3mm
TOP OF PAGE ↑



ARRI Signature Zoom

ARRI Signature - LPL mount

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
24-75 16" 2.8 -22 8: 3oz 114mm 45mm
45-135 4' 3" 2.8 -22 8: 3oz 114mm 45mm
TOP OF PAGE ↑



Angenieux Optimo 17-80

Angenieux EZ - PL or EF mount
S35 or Large Format*

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
Super 35
15-40 2' 2.0 -22 4: 11oz 114mm 30mm
30-90 2' 2.0 -22 4: 11oz 114mm 30mm
Large Format
22-60 2' 3.0 -22 4: 10oz 114mm 46mm
45-135 2' 3.0 -22 4: 10oz 114mm 46mm

*Requires exchange of rear element module by our technician

TOP OF PAGE ↑



Angenieux Optimo family

Angenieux Optimo & HR

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
15-40 2' 2.6 -22 4: 3oz 114mm 31-33mm
28-76 2' 2.6 -22 4: 3oz 114mm 31.4mm
45-120 3' 1" 2.8 -22 2: 13oz 114mm 31.4mm
17-80 2' 2.2 -22 11: lbs. 136mm 28-33mm
24-290** 4' 2.8 -22 24: 5oz 162mm 31-40mm
25-250* HR 5' 7" 3.5 -22 10: 8oz 136mm 28-34mm
With Veydra* Close Focus T-Stop lbs: oz Front Diameter Image Circle
29-348** 4' 3.4 -22 24: 5oz 162mm 38.7mm
30-300* HR 5' 7" 4.2 -22 10: 8oz 136mm 36-43mm
TOP OF PAGE ↑



New life for classic zooms

Veydra 1.2x Expander The Veydra 1.2x expander makes it possible to use zoom lenses from the 35mm Academy format era with current generation Super 35 and larger sensor cameras.
The expander works by enlarging the image circle of vintage zoom lenses from 28mm ➤ 36mm while introducing only a ½ stop of light loss during the process.
  • Original ➤ Converted focal length:
  • Angenieux HR 25-250mm ➤ (30-300mm T4.2)
  • Optimo 24-290mm ➤ (29-348mm T3.4)
  • Cooke 18-100mm ➤ (21.6-120mm T3.6)
  • Cooke 20-100mm ➤ (24-120mm T3.7)
  • Cooke 25-250mm MK3 ➤ (30-300mm T4.5)
TOP OF PAGE ↑




Cooke classic zooms

Cooke Classic

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
20-100 14" 3.1 -22 11: 8oz 144.5mm 28mm
18-100 14" 3.0 -22 13: 13oz 150mm 28mm
25-250 5' 3.7 -22 18: lbs. 150mm 28mm
With Veydra Close Focus T-Stop lbs: oz Front Diameter Image Circle
24-120 14" 3.7 -22 11: 8oz 144.5mm 36mm
21-120 14" 3.6 -22 13: 13oz 150mm 36mm
30-300 5' 4.5 -22 18: lbs. 150mm 36mm

Information about Cooke Varotal/Cinetal image circles

TOP OF PAGE ↑



Fujinon Cabrio ZK 19-90 V2

Cabrio ZK V2

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
19-90 2' 10" 2.8 -22 6: 3oz 114mm 33.5mm

Download full manual Download Link
Download servo unit installation chapter Download Link
VIDEO- How to: Cabrio Servo installation Video link

TOP OF PAGE ↑



Canon CN-E cine zoom

Canon CN-E
PL mount only

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
15.5-47 19" 2.8 -22 4: 13oz 114mm 31.4mm
30-105 23½" 2.8 -22 4: 13oz 114mm 31.4mm
TOP OF PAGE ↑



Canon/Century S2000 150-600

Canon FD Century S2000

Focal length Close Focus T-Stop lbs: oz Image Circle
150-600 10' 5.6 -32 16: 8oz 43mm
TOP OF PAGE ↑



Zeiss 11-110 and Angenieux 11.5-138

Super 16

Focal length Close Focus T-Stop lbs: oz Front Diameter Image Circle
11-110 10" 2.2 -22 4: 8oz 87mm 15mm
11½-138 5' 2.3 -22 7: lbs. 114mm 15mm
TOP OF PAGE ↑
